Brazing Services

Advanced Material Joining

We are a brazing company and global leader in the field of advanced material joining technologies for high vacuum applications. Our brazing services leverage precision vacuum and furnace brazing technologies to provide our customers cost savings, batch processing and the highest quality in the industry.

We braze and clean fire virtually all low vapor pressure metals and ceramics such as OHFC Copper 101,Stainless Steel (SST), Kovar, Monel, Tungsten, Cupro-Nickel, Titanium, Aluminum, Alumina, Silicon Carbide and many more.

Our furnace brazing services or vacuum brazing services are available via consignment or turnkey production services. We encourage the turnkey route because it lowers overall risk for you. Consignment is a good fit when customers are experts in braze-joint design and can provide high-quality pre-machined material for processing. If desired, we can also provide stress-relieving, tempering and secondary finishing operations via our in-house CNC machining department upon request.

Materials & Processes

Brazing Services

Advanced Material Joining

We are a brazing company and global leader in the field of advanced material joining technologies for high vacuum applications. Our services leverage precision vacuum and furnace brazing technologies to provide our customers cost savings, batch processing and the highest quality in the industry.

Our furnace brazing services or vacuum brazing services are available via consignment or turnkey production solutions. We encourage the turnkey route because it lowers overall risk for you. Consignment is a good fit when customers are experts in braze-joint design and can provide high-quality pre-machined material for processing. If desired, we can also provide stress-relieving, tempering and secondary finishing operations via our in-house CNC machining department upon request.

Materials & Processes

14
Brazing Furnaces

Furnace technology provides the highest quality joints and is the only technique well adapted for complex geometries, ceramic-to-metal bonding, large/massive parts, or highly reactive materials because assemblies are heated uniformly and multiple joints are processed simultaneously. We primarily supply services and products into high-vacuum, Ultra-High Vacuum (UHV), or “clean” applications and DO NOT use any flux in our advanced material joining processes. Our services include atmosphere brazing, hydrogen brazing, vacuum furnace brazing services, diffusion bonding, bakeout for high vacuum applications and heat treating.

Furnace Brazing Capabilities

• 10” to 48” Diameter
• Hydrogen Wet or Dry
• High Vacuum 10^-5 & 10^-6
• Inert Gas, Blends, Cascade Controllers

Vacuum Furnace Specifications

• 2 PVT Vacuum Furnaces
• 28” x 28” x 28” Hot Zone
• 48” x 28” x 28” Hot Zone
• Temperature Profile Recording

Benefits of Brazing

A new world of design possibilities opens up with today's Vacuum & Furnace Technologies

Work with us to engineer complex designs never before thought possible; every day we help our customers understand joint design and how to engineer parts for our vacuum and furnace brazing services. We are open and collaborative to discuss your requirements, provide DFM (Design for Manufacturability) guidance and help you actualize a low-cost solution with high yield.

Engineers & Designers

• High-strength leak-free joints
• Complex Geometry is Easy
• Tight Tolerance Assemblies
• Bonding dissimilar materials
• Repeatability & Batch Processing
• Reduce thermal contact resistance
• Uniform Thermal Conductivity
• Negligible distortion or warpage
• Beautiful, clean and bright parts

Purchasing Managers

• Low-Cost Batch processing
• Short Lead Times
• Full TurnKey Capabilities
• Consignment Material
• ISO 9001:2015 Quality System
• ITAR Registered
• 4 hr RFQ Response times
• Quick & Easy Quote & Order
• Highest Quality in Industry

Top Quality Assurance

• Dedicated Closed-Loop CAR
• ECO Document Control System
• Formal DMR / RMA Process
• Incoming and Final Inspection
• Supplier Rating System
• Source Control of Raw Materials
• Batch / Lot-Control Traceability
• Lot Traceability & Serialization
• First Article Inspection Process

Brazing Applications
Products Use Cases

Talk to a VP

Leverage a full spectrum of joining capabilities

Heat sink and Electronics Cooling

Liquid Cold or Cooling Plates

Flat Tube Heat Exchangers

Heat Pipes & Heater Tables

Vacuum Chambers (Semiconductor)

Electro-Static Chucks

Components & Assemblies for Defense

Electric Vehicle (EV) Components

Micro-Channel Heat Exchangers

EV Battery Cooling/Heating

Aluminum Fin Heat Exchangers

UHV Heater Modules

Pressure Vessels of All Sizes

Devices and Assemblies Destined for Space

Subassembly Packaging of Sensors

Hydraulic flow boxes

UHV (Ultra-High Vacuum) Components

Thermodynamic Engines

Deposition Chambers & Stages

Plate Heat Exchangers

Solar Panels & Energy Equipment

RF Power & Linear Accelerators

Vacuum
Brazing
Services

Semiconductor LAM & AMAT Approved Supplier

LAM & AMAT Approved Supplier

We process assemblies in high vacuum furnaces with the multi-zone controls required to accurately control tight tolerances and strong braze joints. Today Altair has innovated ways to braze copper, stainless steel, and other refractory metals to aluminum while avoiding brittle intermetallic phases, leaving a strong and hermetic bond. We have also developed an accurate brazing technique for achieving a 360-degree thermal bond on a heating element surrounded by aluminum.

Semiconductor

Brazing Aluminum

Design Guidelines

Bakeout for
Ultra-High Vacuum UHV Applications

Dual Bell Sauder Bakeout Station

A processing step for UHV (ultra-high vacuum) applications. We continue to add core and complementary capabilities like bakeout and have always been leaders and innovators in this regard.

• 6 Independent Cryogenic Ports
• Two Independent Bells
• x10-9 scale vacuum pressure
• Temp. > 600°C and > 1000°C
• Automated Controls
• Ultra-High Vacuum (UHV)
• Efficient Device Conditioning
• Flexible Configuration
• RGA Measurements

Diffusion Bonding

Material Joining without the use of filler

High compression and temperatures cause atoms to diffuse into the adjacent material for metal, copper, and titanium. This particular bonding process is commonly used on linear accelerators and mini-coolers, where braze joints and braze fillets can shift the resonant frequency of a cavity or add a very thin thermal shunt layer which is avoided in diffusion bonding.

Precision Welding

Includes Tig and Spot Welding

Precision welding rounds out our full spectrum of material joining capabilities to support our contract manufacturing and turnkey services. Welding is both an art and a science. We take pride in our beautiful and full penetration welds because they are a prime example of our commitment to quality and the highest standards of fabrication.

We weld Titanium, Nickel, Stainless Steel, Platinum, Kovar, and Moly for spot, stitch and continuous hermetic (vacuum-tight) welds.
